Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 815
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00008
20 Keypad The technology application is controlled via the keypad.
21 PC The technology application is controlled via the "Free
parameters" of the inverter (PC control).
30 CAN The technology application is controlled by means of
CAN-PDOs via the system bus "CAN on board".
"CAN on board" system bus
40 MCI The technology application is controlled by means of
MCI-PDOs via the MCI-interface of an attached
communication module (e.g. PROFIBUS).
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00007 | Control mode
Data type: UNSIGNED_16
Index: 24568
d
= 5FF8
h
Parameter | Name:
C00008 | Original application|control source
Data type: UNSIGNED_16
Index: 24567
d
= 5FF7
h
Display of the originally selected technology application and the originally selected control mode.
• This parameter shows the selection that was set with C00005
and C00007 before a change in the I/O level or the
application level was carried out.
• For diagnostic purposes, this display serves to determine whether there is a standard interconnection in the
inverter or a change carried out by the user.
Selection list (read only) Info
0 Free|Free Application: Interconnection has been changed.
I/O level: Interconnection has been changed.
10 Free|Terminal0 Application: Interconnection has been changed.
I/O level: "Terminals 0" control mode
12 Free|Terminal2 Application: Interconnection has been changed.
I/O level: "Terminal 2" control mode
14 Free|Terminal11 Application: Interconnection has been changed.
I/O level: "Terminal 11" control mode
16 Free|Terminal 16 Application: Interconnection has been changed.
I/O level: "Terminal 16" control mode
20 Free|Keypad Application: Interconnection has been changed.
I/O level: "Keypad" control mode
21 Free|PC Application: Interconnection has been changed.
I/O level: "PC" control mode
30 Free|CAN Application: Interconnection has been changed.
I/O level: "CAN" control mode
40 Free|MCI Application: Interconnection has been changed.
I/O level: "MCI" control mode
1000 Speed|Free Application: Actuating drive speed
I/O level: Interconnection has been changed.
1010 Speed|Terminal0 Application: Actuating drive speed
I/O level: "Terminals 0" control mode
1012 Speed|Terminal2 Application: Actuating drive speed
I/O level: "Terminal 2" control mode
1014 Speed|Terminal11 Application: Actuating drive speed
I/O level: "Terminal 11" control mode
1016 Speed|Terminal16 Application: Actuating drive speed
I/O level: "Terminal 16" control mode
1020 Speed|Keypad Application: Actuating drive speed
I/O level: "Keypad" control mode
