Lenze 8400 - Page 1043

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1043
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01046
C01047
C01048
C01045/2 1 L_ConvAP_1
: Denominator
C01045/3 1 L_ConvAP_2
: Numerator
C01045/4 1 L_ConvAP_2
: Denominator
C01045/5 1 L_ConvAP_3
: Numerator
C01045/6 1 L_ConvAP_3
: Denominator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01045 | L_ConvAP 1-3: Numerator/denominator
Data type: INTEGER_16
Index: 23530
d
= 5BEA
h
Parameter | Name:
C01046 | L_ConvPA 1-3: byDivision
Data type: INTEGER_8
Index: 23529
d
= 5BE9
h
From version 11.00.00
Setting range (min. value | unit | max. value)
031
Subcodes Lenze setting Info
C01046/1 1 L_ConvPA_1
: Division factor
C01046/2 1 L_ConvPA_2
: Division factor
C01046/3 1 L_ConvPA_3
: Division factor
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01047 | L_GearComp_1: Offset
Data type: INTEGER_16
Index: 23528
d
= 5BE8
h
From version 11.00.00
Setting range (min. value | unit | max. value)
-16383 16383
Subcodes Lenze setting Info
C01047/1 0 L_GearComp_1
: Offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01048 | L_GearComp_1: Num_Denom
Data type: INTEGER_16
Index: 23527
d
= 5BE7
h
From version 11.00.00
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01048/1 1 L_GearComp_1
: Numerator
C01048/2 1 L_GearComp_1
: Denominator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
