15 Parameter reference
15.2 Parameter list
1042
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01040
C01041
C01042
C01045
Parameter | Name:
C01040 | L_SRFG_1..2 linear ramp time
Data type: UNSIGNED_32
Index: 23535
d
= 5BEF
h
From version 04.00.00
Symmetrical acceleration/deceleration time for the ramp function generator
Setting range (min. value | unit | max. value)
0.001 s 999.999
Subcodes Lenze setting Info
C01040/1 100.000 s L_SRFG_1
: linear ramp time
C01040/2 100.000 s L_SRFG_2
: linear ramp time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01041 | L_SRFG_1..2 S-ramp time
Data type: UNSIGNED_32
Index: 23534
d
= 5BEE
h
From version 04.00.00
S-ramp time for jerk-free acceleration
Setting range (min. value | unit | max. value)
0.001 s 50.000
Subcodes Lenze setting Info
C01041/1 0.200 s L_SRFG_1
: S-ramp time
C01041/2 0.200 s L_SRFG_2
: S-ramp time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01042 | L_SRFG_1..2 limitations of output values
Data type: INTEGER_16
Index: 23533
d
= 5BED
h
From version 05.00.00
Limitation of the output values
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C01042/1 100.00 % L_SRFG_1
: Pos. Limit
C01042/2 -100.00 % L_SRFG_1: Neg. Limit
C01042/3 100.00 % L_SRFG_2
: Pos. Limit
C01042/4 -100.00 % L_SRFG_2
: Neg. Limit
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C01045 | L_ConvAP 1-3: Numerator/denominator
Data type: INTEGER_16
Index: 23530
d
= 5BEA
h
From version 11.00.00
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01045/1 1 L_ConvAP_1
: Numerator
