Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1041
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01033
C01034
C01035
Parameter | Name:
C01033 | L_Curve_3: Table X-values
Data type: INTEGER_16
Index: 23542
d
= 5BF6
h
From version 11.00.00
FB L_Curve_3
: X-values for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01033/1 0 X values 1 ... 32 for characteristic function
C01033/...
C01033/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01034 | L_Curve_3: Table Y-values
Data type: INTEGER_16
Index: 23541
d
= 5BF5
h
From version 11.00.00
FB L_Curve_3
: Y-value for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01034/1 0 Y values 1 ... 32 for characteristic function
C01034/...
C01034/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01035 | L_Curve_3: SelectCurve
Data type: UNSIGNED_16
Index: 23540
d
= 5BF4
h
From version 12.00.00
FB L_Curve_3
: Selection of the tensile force profile
Selection list Info
0 Linear tensile force profile Use of L_Curve_3 for tensile force characteristic
1 Linear torque profile
2 Tensile force profile according to
characteristic
Subcodes Lenze setting Info
C01035/1 0: Linear tensile force profile L_Curve_3
: SelectCurve
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
