15 Parameter reference
15.2 Parameter list
1040
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01029
C01030
C01031
Parameter | Name:
C01029 | L_Curve_2: Table Y-values
Data type: INTEGER_16
Index: 23546
d
= 5BFA
h
From version 11.00.00
FB L_Curve_2
: Y-value for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01029/1 0 Y values 1 ... 32 for characteristic function
C01029/...
C01029/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01030 | L_Curve_3: Selected curve type
Data type: UNSIGNED_8
Index: 23545
d
= 5BF9
h
From version 11.00.00
FB L_Curve_3
: Selected curve type
Selection list Info
0Out = 0
1Out = In
2Out = f(In)
3Out = f(table)
4 Out = f(characteristic) From version 12.00.00
Subcodes Lenze setting Info
C01030/1 1: Out = In L_Curve_3
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01031 | L_Curve_3: Input limitation
Data type: INTEGER_16
Index: 23544
d
= 5BF8
h
From version 11.00.00
FB L_Curve_3
: Upper and lower limit for input value
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C01031/1 199.99 % L_Curve_3
: Max. input
C01031/2 -199.99 % L_Curve_3
: Min. input
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
