Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1039
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01025
C01026
C01028
Parameter | Name:
C01025 | L_Curve_2: Selected curve type
Data type: UNSIGNED_8
Index: 23550
d
= 5BFE
h
From version 11.00.00
FB L_Curve_2
: Selected curve type
Selection list
0Out = 0
1Out = In
2Out = f(In)
3Out = f(table)
Subcodes Lenze setting Info
C01025/1 1: Out = In L_Curve_2
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01026 | L_Curve_2: Input limitation
Data type: INTEGER_16
Index: 23549
d
= 5BFD
h
From version 11.00.00
FB L_Curve_2
: Upper and lower limit for input value
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C01026/1 199.99 % L_Curve_2
: Max. input
C01026/2 -199.99 % L_Curve_2
: Min. input
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C01028 | L_Curve_2: Table X-values
Data type: INTEGER_16
Index: 23547
d
= 5BFB
h
From version 11.00.00
FB L_Curve_2
: X-values for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01028/1 0 X values 1 ... 32 for characteristic function
C01028/...
C01028/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
