Lenze 8400 - Page 1038

15 Parameter reference
15.2 Parameter list
1038
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01020
C01021
C01022
C01023
Parameter | Name:
C01020 | L_Odometer_1: Memory length
Data type: UNSIGNED_8
Index: 23555
d
= 5C03
h
From version 04.00.00
FB L_Odometer_1
: No. of measurements
Selection list (Lenze setting printed in bold)
1 1 measurement
2 2 measurements
3 3 measurements
4 4 measurements
5 5 measurements
6 6 measurements
77 measurements
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01021 | L_Odometer_1: Memory type
Data type: UNSIGNED_8
Index: 23554
d
= 5C02
h
From version 04.00.00
FB L_Odometer_1
: If "ring buffer" is selected, it is started again after the measurements set in C01020 and the old
values are overwritten. Otherwise, the measurement stops.
Selection list (Lenze setting printed in bold)
0 No ring buffer
1 Ring buffer
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01022 | L_Odometer_1: Input selection
Data type: UNSIGNED_8
Index: 23553
d
= 5C01
h
From version 04.00.00
FB L_Odometer_1
: Selection of position or speed input
Selection list (Lenze setting printed in bold)
0 Pos input
1V input
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01023 | L_Odometer_1: Edge selection
Data type: UNSIGNED_8
Index: 23552
d
= 5C00
h
From version 04.00.00
FB L_Odometer_1
: No. of the edge triggering the measurement
Selection list (Lenze setting printed in bold)
0 High edge
1Low edge
2High and low edge
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
