Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1037
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01001
C01010
Bit 4 Encoder open circuit: V/f linear active From version 15.00.00
1 ≡ Due to an encoder open circuit, it has been internally
switched to the encoderless V/f characteristic control to
avoid impermissible motor movements.
Bit 5 Speed limit. C909/C910/fdmax
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01000 | MCTRL: Status
Data type: UNSIGNED_16
Index: 23575
d
= 5C17
h
Parameter | Name:
C01001 | Manual entry of motor type
Data type: UNSIGNED_8
Index: 23574
d
= 5C16
h
From version 14.00.00
Selection list
0Automatic
1ASM
2PSM
Subcodes Lenze setting Info
C01001/1 0: Automatic Manual entry of motor type
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01010 | L_ArithmetikPhi 1-3: Function
Data type: UNSIGNED_8
Index: 23565
d
= 5C0D
h
Selection of the internal arithmetics
Selection list
0dnIn1_p
1 dnIn1_p + dnIn2_p
2 dnIn1_p - dnIn2_p
3 dnIn1_p * dnIn2_p
4 dnIn1_p / dnIn2_p
Subcodes Lenze setting Info
C01010/1 0: dnIn1_p L_ArithmetikPhi_1
: Function
C01010/2 0: dnIn1_p L_ArithmetikPhi_2
: Function
C01010/3 0: dnIn1_p L_ArithmetikPhi_3
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
