15 Parameter reference
15.2 Parameter list
1010
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00841
Parameter | Name:
C00841 | 16-bit inputs I/O level
Data type: UNSIGNED_16
Index: 23734
d
= 5CB6
h
Decimal/hexadecimal/bit coded display of 16 bit input values of various blocks of the I/O level
• Non-listed subcodes are "reserved".
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00841/1 LS_AnalogOutput
: nOut1_a (V)
C00841/2 LP_CanOut1
: wState
C00841/3 LP_CanOut1
: wOut2
C00841/4 LP_CanOut1
: wOut3
C00841/5 LP_CanOut1
: wOut4
C00841/6 LP_CanOut2
: wOut1
C00841/7 LP_CanOut2
: wOut2
C00841/8 LP_CanOut2
: wOut3
C00841/9 LP_CanOut2
: wOut4
C00841/10 LP_CanOut3
: wOut1
C00841/11 LP_CanOut3
: wOut2
C00841/12 LP_CanOut3
: wOut3
C00841/13 LP_CanOut3
: wOut4
C00841/14 LS_DisFree_a
: nDis1_a
C00841/15 LS_DisFree_a
: nDis2_a
C00841/16 LS_DisFree_a: nDis3_a
C00841/17 LS_DisFree_a
: nDis4_a
C00841/18 LS_DisFree
: wDis1
C00841/19 LS_DisFree: wDis2
C00841/20 LS_DisFree
: wDis3
C00841/21 LS_DisFree
: wDis4
C00841/22 LP_MciOut
: wState
C00841/23 LP_MciOut
: wOut2
C00841/24 LP_MciOut
: wOut3
C00841/25 LP_MciOut
: wOut4
C00841/26 LP_MciOut
: wOut5
C00841/27 LP_MciOut
: wOut6
C00841/28 LP_MciOut
: wOut7
C00841/29 LP_MciOut
: wOut8
C00841/30 LP_MciOut
: wOut9
C00841/31 LP_MciOut
: wOut10
C00841/32 LP_MciOut
: wOut11
C00841/33 LP_MciOut
: wOut12
C00841/34 LP_MciOut
: wOut13
