15 Parameter reference
15.2 Parameter list
1012
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00843
C00841/110 LP_CanOut4
: wOut3
C00841/111 LP_CanOut4
: wOut4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00841 | 16-bit inputs I/O level
Data type: UNSIGNED_16
Index: 23734
d
= 5CB6
h
Parameter | Name:
C00843 | Binary inputs I/O level
Data type: UNSIGNED_8
Index: 23732
d
= 5CB4
h
Display of the signal status of the binary inputs of different I/O level blocks
• Non-listed subcodes are "reserved".
Selection list
0 False
1 True
Subcodes Info
C00843/1 LS_DigitalOutput
: bRelay
C00843/2 LS_DigitalOutput
: bOut1
C00843/3 LS_DigitalInput
: bCountIn1_Reset
C00843/4 LS_DigitalInput
: bCountIn1_LoadStartValue
C00843/5 LP_CanOut1
: bState_B0
C00843/6 LP_CanOut1
: bState_B1
C00843/7 LP_CanOut1
: bState_B2
C00843/8 LP_CanOut1
: bState_B3
C00843/9 LP_CanOut1
: bState_B4
C00843/10 LP_CanOut1
: bState_B5
C00843/11 LP_CanOut1
: bState_B6
C00843/12 LP_CanOut1
: bState_B7
C00843/13 LP_CanOut1: bState_B8
C00843/14 LP_CanOut1
: bState_B9
C00843/15 LP_CanOut1: bState_B10
C00843/16 LP_CanOut1
: bState_B11
C00843/17 LP_CanOut1
: bState_B12
C00843/18 LP_CanOut1: bState_B13
C00843/19 LP_CanOut1
: bState_B14
C00843/20 LP_CanOut1
: bState_B15
C00843/21 LS_DisFree_b
: bDis1
C00843/22 LS_DisFree_b
: bDis2
C00843/23 LS_DisFree_b
: bDis3
C00843/24 LS_DisFree_b
: bDis4
C00843/25 LS_DisFree_b
: bDis5
C00843/26 LS_DisFree_b
: bDis6
C00843/27 LS_DisFree_b
: bDis7
C00843/28 LS_DisFree_b
: bDis8
C00843/29 LP_CanOut2
: bOut1_B0
C00843/30 LP_CanOut2
: bOut1_B1
C00843/31 LP_CanOut2
: bOut1_B2
