15 Parameter reference
15.2 Parameter list
1016
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00844
C00866
C00843/197 LP_CanOut4
: bOut1_B13
C00843/198 LP_CanOut4
: bOut1_B14
C00843/199 LP_CanOut4
: bOut1_B15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00843 | Binary inputs I/O level
Data type: UNSIGNED_8
Index: 23732
d
= 5CB4
h
Parameter | Name:
C00844 | 32-bit inputs I/O level [incr]
Data type: INTEGER_32
Index: 23731
d
= 5CB3
h
Display of 32-bit input values of different I/O level blocks in [increments]
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Info
C00844/1 LS_DisFree_p
: dnDis1_p
C00844/2 LS_DisFree_p
: dnDis2_p
C00844/3 LS_DisFree_p
: dnDis3_p
C00844/4 LS_DisFree_p
: dnDis4_p
C00844/5 LS_DisFree_p
: dnDis5_p
C00844/6 LS_DisFree_p
: dnDis6_p
C00844/7 LS_DisFree_p
: dnDis7_p
C00844/8 LS_DisFree_p
: dnDis8_p
C00844/9 LP_CanOut1
: dnOut34_p
C00844/10 LP_CanOut2
: dnOut34_p
C00844/11 LP_CanOut3
: dnOut34_p
C00844/12 LP_MciOut
: dnOut34_p
C00844/13 LS_DigitalInput: dnPosIn12_Set_p
C00844/16 LS_RetainData
: dnIn1
C00844/17 LS_RetainData: dnIn2
C00844/18 LS_RetainData
: dnIn3
C00844/19 LS_RetainData
: dnIn4
C00844/25 LP_CanOut4: dnOut34_p
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00866 | CAN input words
Data type: UNSIGNED_16
Index: 23709
d
= 5C9D
h
Display of the 16 bit input values of the CAN interface
"CAN on board" system bus
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
