Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1163
15 Parameter reference
15.4 Selection list - analog signals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
36112 L_FixSet_a_1: nOut_a
36113 L_FixSet_a_1: wSelect
36114 L_FixSet_w_1: wOut
36115 L_FixSet_w_1: wSelect
36116 L_FixSet_w_2: wOut
36117 L_FixSet_w_2: wSelect
36120 L_CalcDiameter_1: nDiameter_a
36121 L_CalcDiameter_1: nReziprDiameter_a
36122 L_CalcDiameter_1: nNReel_v
36123 L_CalcDiameter_1: nDMin_a
36124 L_ProcessCtrl_1: nOut_a
36125 L_ProcessCtrl_1: nOutRed_a
36126 L_ProcessCtrl_1: nDeviation_a
36127 L_ProcessCtrl_1: nDComponent
36128 L_PhiIntegrator_1: nOut16
36129 L_PhiIntegrator_1: nSpeedGearAdd_v
36130 L_PosCtrlLin_1: nNOut_v
36131 L_PosCtrlLin_2: nNOut_v
36132 L_PhiIntegrator_1: nSpeedGear_v
36133 L_DFSET_1: nSetGain_v
36134 L_DFSET_1: nSetGearTrim_v
36135 L_DFSET_1: nSetGearTrim_a
36136 L_DFRFG_1: nOut_v
36137 L_ConvPA_1: nOut_a
36138 L_ConvPA_2: nOut_a
36139 L_ConvPA_3: nOut_a
36140 L_ConvX_1: nOut
36141 L_ConvX_2: nOut
36142 L_ConvX_3: nOut
36143 LS_MotionControlKernel: wGearNum
36144 LS_MotionControlKernel: wGearDenom
36145 L_DFSET_1: nSpeedSetOut_v
36146 L_Curve_2: nOut_a
36147 L_Curve_3: nOut_a
36148 L_Curve_3: nCurveValue_a
36162 L_MFail_1: nNOut_a
42000 LA_NCtrl_In: wCANDriveControl
42001 LA_NCtrl_In: wMCIDriveControl
42002 LA_NCtrl_In: nTorqueMotLim_a
42003 LA_NCtrl_In: nTorqueGenLim_a
42004 LA_NCtrl_In: nPIDVpAdapt_a
42005 LA_NCtrl_In: nPIDActValue_a
42006 LA_NCtrl_In: nMainSetValue_a
42007 LA_NCtrl_In: nAuxSetValue_a
42008 LA_NCtrl_In: nGPAnalogSwitchIn1_a
42009 LA_NCtrl_In: nGPAnalogSwitchIn2_a
42010 LA_NCtrl_In: nGPArithmetikIn1_a
42011 LA_NCtrl_In: nGPArithmetikIn2_a
42012 LA_NCtrl_In: nGPMulDivIn_a
42013 LA_NCtrl_In: nGPCompareIn1_a
42014 LA_NCtrl_In: nGPCompareIn2_a
42015 LA_NCtrl_In: nVoltageAdd_a
Selection list - analog signals
42016 LA_NCtrl_In: nPIDInfluence_a
42017 LA_NCtrl_In: nPIDSetValue_a
42018 LA_NCtrl_In: nPWMAngleOffset
42019 LA_NCtrl_In: nBoost_a
42020 LA_NCtrl_In: wSMControl
42025 LA_NCtrl_In: wFreeIn1
42026 LA_NCtrl_In: wFreeIn2
42027 LA_NCtrl_In: wFreeIn3
42028 LA_NCtrl_In: wFreeIn4
42100 LA_TabPos_In: wCanDriveControl
42101 LA_TabPos_In: wMciDriveControl
42102 LA_TabPos_In: nTorqueMotLim_a
42103 LA_TabPos_In: nTorqueGenLim_a
42104 LA_TabPos_In: nMainSetValue_a
42105 LA_TabPos_In: nAuxSetValue_a
42106 LA_TabPos_In: wMckCtrl1
42107 LA_TabPos_In: wMckCtrl2
42108 LA_TabPos_In: wMckOperationMode
42109 LA_TabPos_In: wPosProfileMode
42110 LA_TabPos_In: wPosProfileNo
42111 LA_TabPos_In: nGPAnalogSwitchIn1_a
42112 LA_TabPos_In: nGPAnalogSwitchIn2_a
42113 LA_TabPos_In: nGPArithmetikIn1_a
42114 LA_TabPos_In: nGPArithmetikIn2_a
Selection list - analog signals
