Lenze 8400 - Page 1168

15 Parameter reference
15.5 Selection list - digital signals
1168
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
32007 LS_DeviceMonitor: bMctrlUVDetected
32008 LS_DeviceMonitor: bMctrlOVDetected
32009 LS_DeviceMonitor: bMctrlMotorPhaseFault
32010 LS_DeviceMonitor: bMctrlEncoderComFault
32011 LS_DeviceMonitor: bMctrlIxtOverload
32012 LS_DeviceMonitor: bMctrlI2xtOverload
32013 LS_MotorInterface: bIdentificationActive
32014 LS_MotorInterface: bFlyingSyncActive
32015 LS_DeviceMonitor: bMctrlTorqueMax
32016 LS_DeviceMonitor: bMctrlNMax
32017 LS_DeviceMonitor: bMctrlFChopReduced
32018 LS_DeviceMonitor: bMctrlMotorPtc
32019 LS_DeviceMonitor: bMctrlMotorTemp
32020 LS_MotorInterface: bDcbActive
32021 LS_DeviceMonitor: bMctrlBrakeChopperFault
32022 LS_MotorInterface: bQspIsActive
32023 LS_MotorInterface: bHlgLoad
32024 LS_MotorInterface: bHlgStop
32025 LS_DeviceMonitor: bMctrlImpActive
32026 LS_DeviceMonitor: bMctrlClampActive
32027 LS_DeviceMonitor: bMctrlMainsFault
32028 LS_DeviceMonitor: bMctrlNmaxForFChop
32029 LS_DeviceMonitor: bMctrlShortCircuit
32030 LS_DeviceMonitor: bMctrlEarthFault
32031 LS_DeviceMonitor: bWirebreakUfLinearActive
32032 LS_DeviceMonitor: bCurrentMonitoringOverload
32033 LS_DeviceMonitor: bSlpsmSpeedOpenLoopControl
32100 LS_DriveInterface: bInit
32101 LS_DriveInterface: bReady
32102 LS_DriveInterface: bReadyToSwitchOn
32103 LS_DriveInterface: bOperationEnable
32104 LS_DriveInterface: bWarning
32105 LS_DriveInterface: bTrouble
32106 LS_DriveInterface: bFail
32107 LS_DriveInterface: bCollectedFail
32108 LS_DriveInterface: bSafeTorqueOff
32109 LS_DriveInterface: bImpIsActive
32110 LS_DriveInterface: bCInhIsActive
32111 LS_DriveInterface: bSafetyIsActive
32112 LS_DriveInterface: bCwCcw
32113 LS_DriveInterface: bNActCompare
32200 LS_MotionControlKernel: bPosCtrlOn_
32201 LS_MotionControlKernel: bSpeedCtrlIOn_
32202 LS_MotionControlKernel: bTorquemodeOn_
32203 LS_MotionControlKernel: bDcBrakeOn_
32204 LS_MotionControlKernel: bMBrakeReleaseOut
32205 LS_MotionControlKernel: bMBrakeReleased
32206 LS_MotionControlKernel: bDeltaPosOn_
32207 LS_MotionControlKernel: bPosDerivativeOn_
32208 LS_MotionControlKernel: bMotorRefOffsetOn_
32209 LS_MotionControlKernel: bQspOn_
32210 LS_MotionControlKernel: bPosBusy
Selection list - digital signals
32211 LS_MotionControlKernel: bPosDone
32212 LS_MotionControlKernel: bHomDone
32213 LS_MotionControlKernel: bHomAvailable
32214 LS_MotionControlKernel: bTorqueLimitAdaptOn_
32215 Reserved: b32215
32216 Reserved: b32216
32217 Reserved: b32217
32218 Reserved: b32218
32219 LS_MotionControlKernel: bFollowErrLim1
32220 LS_MotionControlKernel: bFollowErrLim2
32221 LS_MotionControlKernel: bReadyToOperate
36000 L_And_1: bOut
36001 L_And_2: bOut
36002 L_And_3: bOut
36003 L_Or_1: bOut
36004 L_Or_2: bOut
36005 L_Or_3: bOut
36006 L_Not_1: bOut
36007 L_Not_2: bOut
36008 L_Not_3: bOut
36009 L_DFlipFlop_1: bOut
36010 L_RLQ_1: bQsp
36011 L_RLQ_1: bCwCcw
36012 L_DigitalDelay_1: bOut
36013 L_Compare_1: bOut
36014 L_Compare_2: bOut
36015 L_Compare_3: bOut
36016 L_NSet_1: bRfgEqO
36017 L_DigitalLogic_1: bOut
36018 L_Counter_1: bEqual
36019 L_SignalMonitor_b: bOut1
36020 L_SignalMonitor_b: bOut2
36021 L_SignalMonitor_b: bOut3
36022 L_SignalMonitor_b: bOut4
36023 L_PCTRL_1: bActEqSet
36024 L_NLim_1: bLimitActive
36025 L_DFlipFlop_1: bNegOut
36026 L_And5_1: bOut
36027 L_And5_2: bOut
36028 L_Compare_4: bOut
36029 L_Compare_5: bOut
36030 L_ComparePhi_1: bOut
36031 L_ComparePhi_2: bOut
36032 L_ComparePhi_3: bOut
36033 L_ComparePhi_4: bOut
36034 L_ComparePhi_5: bOut
36035 L_DFlipFlop_2: bOut
36036 L_DFlipFlop_2: bNegOut
36037 L_DigitalDelay_2: bOut
36038 L_DigitalDelay_3: bOut
36039 L_Or_4: bOut
36040 L_DigitalLogic_3: bOut
