15 Parameter reference
15.5 Selection list - digital signals
1170
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
36149 L_PosCtrlLin_2: bInTarget
36150 L_SwitchPoint_1: bOut1
36151 L_SwitchPoint_1: bOut2
36152 L_SwitchPoint_1: bOut3
36153 L_SwitchPoint_1: bOut4
36154 L_DFSET_1: bAck
36155 L_DFSET_1: bFollowingErr
36156 L_DFSET_1: bPosOverflow
36157 L_DFRFG_1: bSync
36158 L_DFRFG_1: bFail
36159 L_Curve_2: bLimit
36160 L_Curve_3: bLimit
36171 L_ConvUnitsToIncr_1: bDataValid
36172 L_ConvUnitsToIncr_2: bDataValid
36173 L_ConvUnitsToIncr_3: bDataValid
36177 L_MFail_1: bActive
36178 L_MFail_1: bNCtrlIReset
36179 L_Curve_3: bLimit
36284 L_MckStateInterface_1: bReadyToOperate
36293 L_DigitalLogic_1: bOut2
36294 L_DigitalLogic_1: bOut3
36295 L_DigitalLogic_2: bOut2
36296 L_DigitalLogic_2: bOut3
36297 L_DigitalLogic_3: bOut2
36298 L_DigitalLogic_3: bOut3
42000 LA_NCtrl_In: bCInh
42001 LA_NCtrl_In: bFailReset
42002 LA_NCtrl_In: bSetQuickstop
42003 LA_NCtrl_In: bSetDCBrake
42004 LA_NCtrl_In: bRFG_Stop
42005 LA_NCtrl_In: bRFG_0
42007 LA_NCtrl_In: bSetSpeedCcw
42008 LA_NCtrl_In: bJogSpeed1
42009 LA_NCtrl_In: bJogSpeed2
42010 LA_NCtrl_In: bJogSpeed4
42011 LA_NCtrl_In: bJogSpeed8
42012 LA_NCtrl_In: bJogRamp1
42013 LA_NCtrl_In: bJogRamp2
42014 LA_NCtrl_In: bJogRamp4
42015 LA_NCtrl_In: bJogRamp8
42017 LA_NCtrl_In: bMPotInAct
42018 LA_NCtrl_In: bMPotUp
42019 LA_NCtrl_In: bMPotDown
42020 LA_NCtrl_In: bMBrakeRelease
42021 LA_NCtrl_In: bGPFree1
42022 LA_NCtrl_In: bGPFree2
42023 LA_NCtrl_In: bGPAnalogSwitchSet
42024 LA_NCtrl_In: bGPDigitalDelayIn
42025 LA_NCtrl_In: bGPLogicIn1
42026 LA_NCtrl_In: bGPLogicIn2
42027 LA_NCtrl_In: bGPLogicIn3
42028 LA_NCtrl_In: bGPDFlipFlop_InD
Selection list - digital signals
42029 LA_NCtrl_In: bGPDFlipFlop_InClk
42030 LA_NCtrl_In: bGPDFlipFlop_InClr
42031 LA_NCtrl_In: bMPotEnable
42032 LA_NCtrl_In: bPIDEnableInfluenceRamp
42033 LA_NCtrl_In: bPIDIOff
42034 LA_NCtrl_In: bRLQCw
42035 LA_NCtrl_In: bRLQCcw
42041 LA_NCtrl_In: bFreeIn1
42042 LA_NCtrl_In: bFreeIn2
42043 LA_NCtrl_In: bFreeIn3
42044 LA_NCtrl_In: bFreeIn4
42045 LA_NCtrl_In: bFreeIn5
42046 LA_NCtrl_In: bFreeIn6
42047 LA_NCtrl_In: bFreeIn7
42048 LA_NCtrl_In: bFreeIn8
42100 LA_TabPos_In: bCInh
42101 LA_TabPos_In: bFailReset
42102 LA_TabPos_In: bSetQuickstop
42103 LA_TabPos_In: bSetSpeedCcw
42104 LA_TabPos_In: bJogSpeed1
42105 LA_TabPos_In: bJogSpeed2
42106 LA_TabPos_In: bMPotEnable
42107 LA_TabPos_In: bMPotUp
42108 LA_TabPos_In: bMPotDown
42109 LA_TabPos_In: bMBrakeRelease
42110 LA_TabPos_In: bPosCtrlOn
42111 LA_TabPos_In: bLimitSwitchPos
42112 LA_TabPos_In: bLimitSwitchNeg
42113 LA_TabPos_In: bReleaseLimitSwitch
42114 LA_TabPos_In: bManJogPos
42115 LA_TabPos_In: bManJogNeg
42116 LA_TabPos_In: bManEnable2ndSpeed
42117 LA_TabPos_In: bEnableSpeedOverride
42118 LA_TabPos_In: bEnableAccOverride
42119 LA_TabPos_In: bHomeStartStop
42120 LA_TabPos_In: bHomeSetPosition
42121 LA_TabPos_In: bHomeResetPosition
42122 LA_TabPos_In: bHomeMark
42123 LA_TabPos_In: bPosSetProfilePosition
42124 LA_TabPos_In: bPosSetActualPosition
42125 LA_TabPos_In: bPosExecute
42126 LA_TabPos_In: bPosFinishTarget
42127 LA_TabPos_In: bPosDisableFollowProfile
42128 LA_TabPos_In: bPosStop
42129 LA_TabPos_In: bGPAnalogSwitchSet
42130 LA_TabPos_In: bGPDigitalDelayIn
42131 LA_TabPos_In: bGPLogicIn1
42132 LA_TabPos_In: bGPLogicIn2
42133 LA_TabPos_In: bGPLogicIn3
42134 LA_TabPos_In: bGPDFlipFlop_InD
42135 LA_TabPos_In: bGPDFlipFlop_InClk
42136 LA_TabPos_In: bGPDFlipFlop_InClr
Selection list - digital signals
