16 Working with the FB Editor
16.4 Reconfiguring the predefined interconnection
1216
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5. Select the system block to be inserted in the Search results list field.
6. Click the Insert button.
• The dialog box is closed and the selected system block is inserted into the
interconnection.
Context menu for the system block
If you right-click on the header of a system block, a context menu opens via which you can execute
the following functions in addition to the general processing functions (Copy, Insert, Delete):
Related topics
Deleting objects that are no longer required
( 1221)
Changing connector visibilities
( 1222)
Arranging objects in the drawing area
( 1223)
Creating/deleting connections
( 1224)
Command Function
Centre Move the visible cutout of the drawing area so that the block is centred.
Connector visibilities... Define visible inputs and outputs of the block.
Changing connector visibilities
( 1222)
Online display format... Adapt the display format of the input and output data of the block
individually for online monitoring.
Change online display format
( 1210)
Parameters... Open the parameter list/parameterisation dialog for the block.
Help Show online help for the block.
