17 Function library
17.1 Function blocks
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Related topics:
Overview of system blocks available
( 1529)
Working with the FB Editor
( 1191)
L_SRFG_1
L_SRFG_2
2 μs ... is a ramp function generator with S-shaped ramps for limiting the
temporal rise of analog signals.
• These FBs are available from version 04.00.00.
L_SwitchPoint_1
3 μs ... provides four position switch points, i.e. digital switches the binary
statuses (FALSE/TRUE) of which depend on the actual position.
• This FB is available from version 11.00.00.
L_Transient_1
L_Transient_2
L_Transient_3
L_Transient_4
L_Transient_5
L_Transient_6
L_Transient_7
L_Transient_8
3 μs ... evaluates digital signal edges and converts them into timed pulses.
• The L_Transient_5-8 function blocks are available from version
04.00.00.
Function block Runtime Function
