17 Function library
17.1 Function blocks | L_DigitalLogic5_2
1379
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Example:
If in case of the signal combination bln1 =TRUE, bln2 =FALSE, bln3 =TRUE, bIn4 =TRUE
and bIn5 =TRUE, the output signal bOut is to be = TRUE, C00827/30
must be set to "TRUE":
FALSE FALSE FALSE TRUE FALSE C00827/3 (FALSE or TRUE)
... C00827/...
(FALSE or TRUE)
TRUE TRUE TRUE FALSE TRUE C00827/30
(FALSE or TRUE)
TRUE TRUE TRUE TRUE FALSE C00827/31
(FALSE or TRUE)
TRUE TRUE TRUE TRUE TRUE C00827/32
(FALSE or TRUE)
bIn5 bIn4 bIn3 bIn2 bIn1 Output signal bOut
TRUE TRUE TRUE FALSE TRUE C00827/30
(TRUE)
bIn5 bIn4 bIn3 bIn2 bIn1 Output signal bOut
