Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1408
17 Function library
17.1 Function blocks | L_MFail_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Combination of the above shown proceedings
The combination of the proceedings can be simply realised via an OR operation:
[17-45] Interconnection example 3: Mains failure control of different sources
