6 I/O terminals

6.3 Analog terminals

348

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Parameterisation dialog in the »Engineer«:

Button Function

Parameterising analog input

( 350)

Parameterising analog output

( 354)

Open the parameterising dialog for assigning application inputs to the analog input.

Changing the terminal assignment with the »Engineer«

( 369)
