8 Basic drive functions (MCK)
8.4 Basic settings
534
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Case studies for modulo positioning
In the following, some case studies with the different positioning modes are represented. The target
positions are defined by the user.
Positioning mode "absolute (shortest path)"
Case 1 Case 2 Case 3 Case 4
Positioning mode "absolute (Cw)"
Case 1 Case 2 Case 3 Case 4
Positioning mode "absolute (Ccw)"
Case 1 Case 2 Case 3 Case 4








































































