9 Diagnostics & error management
9.3 Drive diagnostics with the »Engineer«
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
 How to diagnose a drive with the »Engineer«:
1. Go to the Project view and select the 8400 HighLine inverter.
2. Click the icon or select the OnlineGo online command to build up an online
connection with the inverter.
3. Select the Diagnostics tab.
• With an online connection, the Diagnostics tab displays current status information
about the inverter.
 Tip!
The online connection to the inverter can be established via the following device interfaces:
•CAN interface X1
Diagnostics via the System bus "CAN on board"
( 700)
• X6 diagnostic interface
We recommend this diagnostic connection when the X1 CAN interface is used for
process communication.
