Lenze 8400 - Page 793

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 793
14 Parameter change-over
14.1 Configuring parameter change-over via the »Engineer« parameterisation dialog
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Copying values
All the settings of a value set can be copied to another value set.
 To copy values, proceed as follows:
1. Click on the Copy values button.
•The Copy values dialog box is displayed:
2. Define the parameter list to be copied via the two upper checkboxes.
3. Select Source and Target.
4. Click on button in order to copy the values from Source to target.
Importing/exporting the list
For cross-device
reuse of the configured WriteParamList, you can click on the Export and Import
buttons to save the parameter selection as an *.epc file and then to re-import the saved *.epc file
into another 8400 inverter.
