C00620
Parameter | Name:
C00620 | System connection list: 16-bit
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Connection parameters: 16-bit inputs
• Selection of the 16 bit output signals to be connected to the 16 bit input signals
• The selection list contains all 16 bit output signals which can be assigned to the 16 bit inputs displayed by the
subcodes.
• Non-listed subcodes are "reserved".
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00620/1 1003: LA_NCtrl: nMotorSpeedAct_a LS_AnalogOutput
: nOut1_a (V)
Analog output 1: Voltage
C00620/2 0: Not connected LP_CanOut1
: wState
CAN1 output: Status word
C00620/3 0: Not connected LP_CanOut1
: wOut2
CAN1 output: Data word 2
C00620/4 0: Not connected LP_CanOut1
: wOut3
CAN1 output: Data word 3
C00620/5 0: Not connected LP_CanOut1
: wOut4
CAN1 output: Data word 4
C00620/6 0: Not connected LP_CanOut2
: wOut1
CAN2 output: Data word 1
C00620/7 0: Not connected LP_CanOut2
: wOut2
CAN2 output: Data word 2
C00620/8 0: Not connected LP_CanOut2
: wOut3
CAN2 output: Data word 3
C00620/9 0: Not connected LP_CanOut2
: wOut4
CAN2 output: Data word 4
C00620/10 0: Not connected LP_CanOut3
: wOut1
CAN3 output: Data word 1
C00620/11 0: Not connected LP_CanOut3
: wOut2
CAN3 output: Data word 2
C00620/12 0: Not connected LP_CanOut3
: wOut3
CAN3 output: Data word 3
C00620/13 0: Not connected LP_CanOut3
: wOut4
CAN3 output: Data word 4
C00620/14 0: Not connected LS_DisFree_a
: nDis1_a
Display of analog signal 1
C00620/15 0: Not connected LS_DisFree_a
: nDis2_a
Display of analog signal 2
C00620/16 0: Not connected LS_DisFree_a
: nDis3_a
Display of analog signal 3
C00620/17 0: Not connected LS_DisFree_a
: nDis4_a
Display of analog signal 4
C00620/18 0: Not connected LS_DisFree
: wDis1
Display of 16-bit signal 1
C00620/19 0: Not connected LS_DisFree
: wDis2
Display of 16-bit signal 2
C00620/20 0: Not connected LS_DisFree
: wDis3
Display of 16-bit signal 3
