Malfunctions in driving mode
8.6 Tilting/lowering the driver's cab
Operating manual 3 302 736 en 8 - 45
GMK4090
xx.xx.xxxx
Tilting the driver's
cab
• Remove all loose objects from the driver's cab. Close the doors.
• Open the front flap; à Front flap, p. 3 - 72.
• Check that the lever is pointing forwards (2) (A).
• Use the lever to pump (1) – the driver's cab lock opens and the rear of the
driver's cab is lifted up.
s
G
Risk of accidents from loose objects and doors swinging open
Remove all loose objects (e.g. bottles) from the driver's cab so that they do
not fall out when the cab is tilted. Close the doors.
This prevents e.g. liquids from getting into the instrument panels and doors
from swinging open during tilting, thereby injuring people.
G
Risk of accidents due to driver's cab tilting
When you are tilting the driver's cab forward and while it is actually tilted
forward, no-one may be in front of the driver's cab.
S
Risk of damage when the main boom angle is too small
Only tilt the driver's cab when the main boom is sufficiently raised.
If you press the driver's cab against the main boom, the driver's cab may
tear off at the pivot point and the steering will be damaged.
S
Risk of damage to front flap and the driver's cab!
The driver's cab may only be tilted if the front flap is open. This avoids dam-
age to the front flap and the bumper.
