Malfunctions in driving mode
8.7 Fuses on the carrier
Operating manual 3 302 736 en 8 - 49
GMK4090
xx.xx.xxxx
8.7 Fuses on the carrier
The fuses are divided into groups and are at various points on the carrier:
– In the driver's cab,
– In the battery box.
Information on
changing fuses
The positions of the fuses, their designations and which functions are pro-
tected by the respective fuses are shown in the following sections.
• Switch off the ignition whenever a fuse has to be replaced.
S
Risk of damage if the ignition is switched on
Switch off the ignition whenever a fuse has to be replaced. This prevents
the new fuse being blown immediately by the increased starting current
after being installed.
S
Risk of damage by overloading
Replace blown fuses only with new fuses of the same amperage. This pre-
vents parts being overloaded and damaged or the fuse being immediately
blown again.
Notify
Manitowoc Crane Care if a fuse with the same amperage blows again
when the ignition is switched on.
S
Risk of fire
Never repair a blown fuse with other electrically conductive materials.
