Malfunctions in driving mode
8.7 Fuses on the carrier
8 - 52 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Designation
Amper-
age (A)
Function
F4/1 3 Cab lighting
F4/2 20 Dual tank switchover
F4/3 5
CCS display
F4/4 - Unassigned
F4/5 - Unassigned
F4/6 - Unassigned
F4/7 - Unassigned
F4/8 - Unassigned
Designation
Amper-
age (A)
Function
F5/1 20 auxiliary heater
F5/2 3
Control unit UE CCM 11
Control unit UE 2 IOL 31/32/33
F5/3 10 Radio
F5/4 5 Tachograph, instrument panel
F5/5 10 Fan
F5/6 - Unassigned
F5/7 - Unassigned
F5/8 5 Power supply relay
