Malfunctions in driving mode
8.7 Fuses on the carrier
Operating manual 3 302 736 en 8 - 51
GMK4090
xx.xx.xxxx
s
Designation
Amper-
age (A)
Function
F2/1 15 Control unit UB 1 IOL 31
F2/2 15 Control unit UB 1 IOL 31
F2/3 15 Control unit UB 2 IOL 31
F2/4 15 Control unit UB 2 IOL 31
F2/5 15 Control unit UB 1 IOL 32
F2/6 15 Control unit UB 1 IOL 32
F2/7 15 Control unit UB 2 IOL 32
F2/8 15 Control unit UB 2 IOL 32
Designation
Amper-
age (A)
Function
F3/1 15 Control unit UB 1 IOL 33
F3/2 15 Control unit UB 1 IOL 33
F3/3 15 Control unit UB 2 IOL 33
F3/4 15 Control unit UB 2 IOL 33
F3/5 10 ABS control unit
F3/6 10 ABS control unit
F3/7 15 Cigarette lighter, voltage transformer
F3/8 - Unassigned
