Operating elements for crane operation
9.2 Short description of the operating elements
9 - 96 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Exiting the menu/input mode
Press button (1) or (2) to exit the menu or input mode.
Overview menu groups
Switch off the
RCL buzzer
In some cases not active until after 5 seconds
Jog dial display
Sensor for brightness
Registers the brightness of the operating environment. The brightness of all
displays is automatically adjusted;
à Display – setting the brightness,
p. 10 - 6.
– Press the button
once:
– The opened menu closes – the menu from the
next higher level is opened
– Input mode is deactivated
1Press: – After the first press
Menu groups overview display
– After a subsequent press
Next/previous group overview
– Press once: Buzzer is switched off
1 Jog Dial OK
2 Jog Dial not working
Communication fault or error (error display)
