Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual 3 302 736 en 9 - 119
GMK4090
xx.xx.xxxx
CCS display
Power units display
High-speed mode inspection derricking gear
Side panel
– Green: Derricking gear on
–Red: Derricking gear off
– Lights up: High-speed mode on
– Go out: High-speed mode off
à p. 11 - 111
1 Raise enable button after RCL shutdown
RCL override – version A;
à p. 9 - 141.
RCL override – version B;
à p. 9 - 142.
