Overview
1.5 Technical data
Operating manual 3 302 736 en 1 - 11
GMK4090
xx.xx.xxxx
Hook blocks and
hook tackle
Lifting capacity of the hook blocks; à p. 12 - 134.
Versions as execution as separable hook block
s
Dimensions (m)
and weights (kg)
(1) (2) (3) (4) (5) (6)
Length 1,98 0,90 1,20 1,98 0,90 1,30
Width 0,70 0,70 0,70 0,70 0,70 0,70
Height 0,76 0,32 0,76 0,76 0,45 0,76
Weight in kg 960 275 685 1,600 465 1,135
