Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating manual 3 302 736 en 14 - 75
GMK4090
xx.xx.xxxx
s
Designation Amper-
age (A)
Function
F4/1 3 Control unit UE IOL 30, CCM 10, UE SCM
F4/2 5 UE CCM, UE IOL 34, IOS 22
F4/3 3 CraneSTAR system
F4/4 10 Radio
1)
F4/5 – Unassigned
F4/6 – Unassigned
F4/7 – Unassigned
F4/8 3 Rotating beacon
1)
Designation Amper-
age (A)
Function
F5/1 5
Control unit 15 SCM, CCM 10
Control unit UE IOL 30, IOS 22
F5/2 5 Control unit 15 UE IOS 20 and 21
F5/3 3
CCS display
F5/4 3 Control lever CAN bus system
F5/5 5 Control lever supply
F5/6 – Unassigned
F5/7 – Unassigned
F5/8 5 Switch lighting
1)
Additional equipment
