Malfunctions during crane operation
14.8 Fuses in the crane cab
14 - 76 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Designation Amper-
age (A)
Function
F6/1 10 Windscreen washing system
F6/2 15 Sockets 12 V
F6/3 10 Crane cab spotlight
F6/4 15 Main boom spotlight
F6/5 5 House Lock
F6/6 3
CraneSTAR system
Spotlight variable motor
F6/7 3 Radio control
1)
F6/8 5 Camera system
1)
Designation Amper-
age (A)
Function
F7/1 3 Rotating beacons
F7/2 5 Diagnostic connection
F7/3 3 heating system
F7/4 3 Telescoping step, crane cab
1)
F7/5 – Unassigned
F7/6 3 Separate display, camera system
1)
F7/7 – Unassigned
F7/8 – Unassigned
Designation Amper-
age (A)
Function
F8/1 5 Crane control power supply
F8/2 3 Crane control power supply
F8/3 3 Crane control power supply
F8/4 3 Crane control power supply
F8/5 – Unassigned
F8/6 – Unassigned
F8/7 – Unassigned
F8/8 3 Crane control power supply
1)
Additional equipment
