Operator’s Manual 10 - 1
10 Display & Cine Review
10.1 Splitting Display
The system supports dual-split display format. However, only one window is active.
Dual-split:
1. Select [Dual] to be “on” from B image menu to enter dual-split mode.
2. Tap each window to switch the active window (marked with “m” icon.)
3. Tap [B] or select [Dual] to be “Off” to exit to single window.
10.2 Image Magnification
Zooming an image changes the frame rate which tends to change thermal indices. The position of
the focal zones may also change which may cause the peak intensity to occur at a different location
in the acoustic filed.As a result, the MI may change.
Use two fingers to pinch on the image area to zoom in/out the image.
For the following mode, you need to tap [Image] > [B] to highlight B menu first:
• B+Color
•B+M
•B+PW
• B+Color+PW
• B+Power+PW
10.3 iZoom (Full-screen Zooming)
This feature magnifies the image area in full screen for a better observation.
• To enter iZoom:
Swipe the screen from the top to the bottom.
• To exit iZoom:
Swipe the screen from the bottom to the top.
10.4 Freeze/Unfreeze the Image.
Tap [Freeze] in the bottom-right corner of the operating panel to freeze a scanning image. In freeze
mode, the probe stops transmitting acoustic power, and all images and parameters are frozen.
