B - 2 Operator’s Manual
B Wireless LAN
Wi-Fi function is not affected when the system is imposed with radiation interference complied
with IEC60601-1-2:2014 standard.
B.1 Use the Wireless feature
Perform the following procedure:
1. Tap in the top-right part of the screen to open the wireless network manager.
2. Tap to select the target network, tap [Connect] to connect to the network.
When connecting an encrypted network, enter the password in the box first. You can select to
hide password characters or not.
3. The system tries to connect to the selected network. The icon turns into or after
successful connection.
4. Tap [Refresh] to refresh the “Wireless Network Connection” list.
B.1.1 IP Configure
• When the system background is processing network task (DICOM sending for example),
please do not enter network setting to change the IP, otherwise the background task may fail.
You can check if there are tasks undergoing in the task manager.
• If the IP address displays as 0.0.0.0, this means that the network is abnormal. The reason for
the failure may be disconnection or the system cannot obtain the IP address.
IP config is used for setting local network parameters, which is also applied to DICOM connection.
Perform the following procedure:
1. In Wireless network manager screen, click [IP Config] to open the page.
– If “DHCP” is selected, the IP address will be automatically obtained from the DNS server.
– If “Static” is selected (using a static IP address), enter the IP address.
IP address of the system should be in the same network segment with the server.
2. Tap [Save] to save current setting. Tap [Cancel] to exit.
B.1.2 EAP Network
For setting EAP network, contact Mindray Customer Service Department or the sales
representatives.
B.2 Specifications
Table B-1 Wireless specification and technology
Item Specifications
Standards IEEE 802.11 b/g/n
Modulation mode 802.11b: DSSS
802.11g/n: OFDM
