12 Annotations and Body Marks
Operator’s Manual 12 - 3
12.2.1 Adding Body Mark
Perform the following procedure:
1. Select [Annotate] > [Body Markers] on the operating panel to enter Body Mark status as well
as open the body marker menu.
2. Tap to select the desired body mark to bring out the Position Probe Marker dialog box.
3. To adjust the probe position and orientation marker:
– Tap and rotate the bold solid green line to position the probe marker.
– Tap and rotate the dotted line to adjust the probe marker orientation.
4. Tap [Set] to confirm the position and orientation of the probe marker and add the mark.
12.2.2 Moving Body Marks
You can move the body mark graphics to any desired position within the image area.
In Dual B Mode, a Body Mark cannot be moved between the separate image windows.
Perform the following procedure:
1. Tap to select the body mark. The body mark is covered by a green frame, indicating you can
move it to a new position.
2. Tap the desired position to place the body mark.
12.2.3 Deleting Body Marks
Tap [Clear Markers] to delete the added body mark on the body marker menu.
12.3 Voice Comments
The system supports adding voice comment to the frozen images.
• In voice comment recording status, you can perform measurements, comments adding, body
marks adding, print tasks and DICOM tasks.
• If you tap [Freeze] during the recording course, the already recorded voice comment cannot be
saved.
12.3.1 Voice Comment Panel
After the system enters the voice comment status, the voice comment panel will be displayed.
