2 - 8 Operator’s Manual
2 System Overview
• When connecting an external video device (HDMI/VGA), make sure the display resolution
setting is 1920×1080, otherwise the image quality may be degraded.
• For a better audio/video signal performance, please connect the module to the ultrasound
system before the system is powered on.
2.9 ECG Module
Figure 2-3 ECG module
No. Name Description
1. Serial connector Connects to the serial port for connecting to ECG of the
system.
NOTE:
Ensure the system is powered off before connecting the
ECG module.
2. ECG lead port Used for ECG signal input.
1
2
