Operator’s Manual J - 1
J Acoustic Power Data and Surface
Temperature Data
This manual gives all the transducers Acoustic Output Power data and Surface Temperature Data
for this Diagnostic Ultrasound System. Please refer to correlative tables in use.
The acoustic output data of transducers are shown respectively in the following imaging modes.
The mode in the parenthesis refers to the imaging mode mentioned in this Manual.
•B-Mode
•M-Mode
•PW-Mode
•B+M-Mode
•PW+B-Mode
• Color + B-Mode
• Power + B-Mode
• PW +Color+ B-Mode
• Power + PW +B-Mode
• Color M-Mode
• Tissue Harmonic Imaging
•Free Xros M
• Contrast imaging (Contrast agent for Liver)
•ViTE
J.1 Description of symbols used in acoustic output
tables
Symbol Description
MI Mechanical Index. The value of MI at the location of the maximum
attenuated pulse-intensity integral.
TIS Soft-Tissue Thermal Index
TIS
as,sc
Soft-Tissue Thermal Index at-surface, scanning
TIS
as,ns
Soft-Tissue Thermal Index at-surface, non-scanning
TIS
bs,sc
Soft-Tissue Thermal Index below surface, scanning
TIS
bs,ns
Soft-Tissue Thermal Index below surface, non-scanning
TIB Bone Thermal Index
TIB
as,sc
Bone Thermal Index at-surface, scanning
To Next Page
