11 - 30 Operator’s Manual
11 Measurement and Report
• Only measurement values are editable, while calculation values and ViTE data are not.
• After a measurement value is modified, the corresponding calculation value will be updated
automatically.
The measurement values in the text boxes are editable. Move the cursor to the text box and tap on
the screen to type on the popped up keyboard.
Entering Ultrasound Remarks
In the [Comments] box, enter the corresponding information.
Selecting Images
Images saved for the current exam can be added to the report.
Perform the following procedure:
1. Tap [Image] on the report page to bring up the following dialog box.
2. Select the image by tap on the check box at the upper left corner of the image.
3. Tap [Done] to confirm.
Analyzing Report Data
You can preset and edit anatomy information in the OB report.
Descriptions of [Fetus Score] can only be selected from the drop-down list.
Perform the following procedure:
1. Tap [Checklist].
2. Select or enter anatomy descriptions.
3. Drag the page downward to see more measurement values.
4. Tap on [Done] to confirm. Analysis information displays after the measurement values in the
report.
11.5.3 Obstetric Exam Report
Fetal Biophysical Profile
Fetal Biophysical Profile means to first obtain a few indices related to fetal growth through
experiment or measurement and then evaluate the hazardous situation that the fetus is facing by
grading these indices respectively.
Tap [Checklist] on the OB report page, the fetus Score is listed after the fetal analysis.
The scoring criteria the system provides are based on the Vintzileos formula, as shown in the table
below.
Fetal growth
index
Score 0 Score 2 Observation
time
FHR <2, or Reactive FHR ≤15 bpm Reactive FHR ≥ 15 bpm,
duration ≥ 15 s, ≥2 times
30 minutes
FM ≥ 2 fetal movements FM ≥ 3 times (continuous
movement is deemed as 1 time)
30 minutes
