14 - 6 Operator’s Manual
14 DICOM/HL7
14.7.3 Data Restore
Only system-accessible media can be selected.
After the DICOM format data are saved to external media, restore the data to the ultrasound system.
Connect the external media containing DCM files to the system.
1. In iStation, review the data stored on the external media.
2. Select the data to be restored in iStation.
3. Tap [Option] > [Restore] on the iStation screen.
14.8 Structured Report
The Structured Report (SR) can be sent with meeting the following procedures:
• DICOM structured report installed with the corresponding exam mode;
• The state of the SR should be “Cancel” or “Stop”.
• Set the storage option to “Attach SR When Store Images” or “Only Store SR”, see
“4.3.2 DICOM Service Preset”.
Only the PACS system from the Medstreaming company (http://www.medstreaming.com/
default.aspx) supports sending self-defined measurements by DICOM SR.
14.8.1 Send structured reports for storage
Perform the following procedure:
1. Create new patient information or load scheduled patient information.
2. Perform measurements.
3. Save the images.
4. End the exam.
5. Open the iStation screen, select the patient exam, and tap [Send To] to open the Send To dialog
box.
6. Select “DICOM” in the Target box on the left side, then select the DICOM storage server in
the Storage Server box on the right side.
7. Tap [Send]. Check for the result in the DICOM Task Management dialog box.
The structured report can be sent automatically.
14.8.2 Back up structured report
When recording or storing exams that have structured reports to external media (DICOMDIR), the
structured reports can be backed up together.
