V Series Operating Instructions 9 - 25
ECG – Arrhythmia Arrhythmia Algorithm
9.6.8.1 About the QT/QTc Tile
• The QT/QTc tile displays the QT/QTc in unit of ms with a resolution of 1 ms.
• The QT/QTc tile displays the QT-HR in unit if BPM with a resolution of 1 BPM.
• If the measurement is invalid, “--” displays in place of digits.
9.6.8.2 QT/QTc Alarms
Refer to "ECG Analysis Leads" on page 9-23 for additional information.
9.6.8.3 Message Area
The message area provides information about the current state of the QT/QTc parameter.
MESSAGE DETAILS
QTc High Alarm Violation Indicates that the current value is either equal to or higher than the set
alarm limits.
