V Series Operating Instructions 1 - 9
General Product Description V 12/V 21 Physical Views
1.3.4 Right Side Panel
1. Handle
2. Diagnostics port
3. MR 1 connectors
4. Side grip/actuator
5. Battery compartment
6. Power button
FIGURE 1-6 Example V 12 Right Side Panel
4
1
2
5
6
3
