SvO2 Configuration Mixed Venous Oxygen Saturation (SvO2) (Optional)
4 - 4 Addendum to V Series Operating Instructions
TABLE 4-2 contains the alarm responses for the CCO/Hemo parameter.
4.2.4 Configuring the SvO2 Parameter
1. Select the SvO2 digital tile.
2. Select the Setup tab (as shown in FIGURE 4-3).
NOTE: The current parameter setting displays in bold to the right of each
button.
FIGURE 4-3 Example SvO2 Dialog (Setup Tab)
TABLE 4-2
ALARM LEVELS*
FACTORY
DEFAULT ALARM RESPONSES
ALARM LEVELS
BUTTON HIGH MEDIUM LOW
PRINT ON
ALARM
SAVE TO
EVEN
T
NURSE
CALL
SvO2 X X X Off On Off
* X indicates available alarm level
** The factory default configuration settings are in bold.
