Mindray V Series - 12 Lead Report

12 Lead Interpretation ECG – Arrhythmia
9 - 36 V Series Operating Instructions
5. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
9.9.2 12 Lead Report
Select the Print 12 Lead button to print the 12 Lead report. Refer to "12 Lead Report" on page 20-10
for additional information.
TABLE 9-7
BUTTON DESCRIPTION CHOICES*
QTc Formula Configure the formula used in
calculating the QTc.
Hodges, Bazett, Fridericia, and Framingham
For details about QTc formulas, refer to the
Glasgow Program Physician’s Guide (P/N
046-004985-00)
Waveform
Layout
Configure the waveform layout. Standard and Cabrera
Report Format Configure the report format. Standard, Representative Complexes and
Matrix
Baseline Drift
Removal
Configure the 12 lead baseline drift
removal filter.
On and Off
Muscle Artifact
Filter
Configure the 12 lead myoelectric filter. On and Off
NOTE: The original signal is 0.05 Hz to 150 Hz. If Baseline Drift Removal is
configured to On, the signal lower limit is changed into 0.56 Hz. If
Muscle Artifact Filter is configured to On, the signal upper limit is
changed into 40 Hz.
NOTE: Application of the Baseline Drift Removal filter will affect the
printed 12-Lead report and the data applied to the interpretation
algorithm which may affect the measurements on the 12-Lead
report. Application of the Muscle Artifact filter will affect only the
printed 12-lead waveforms on 12-Lead report. Application of the
Baseline Drift Removal and Muscle Artifact filters do not affect the
real time display or any other reports.
*The factory default configuration settings are in bold.
