rSO2 Configuration Regional Oxygen Saturation (rSO2) (Optional)
3 - 4 Addendum to V Series Operating Instructions
3.2.4 Configuring the rSO2 Parameter
• Select the rSO2 digital tile.
OR
1. Select the Setup tab from the Navigation Area.
2. Select the Parameters button.
3. Select the rSO2 button.
The rSO2 dialog displays.
NOTE: The current parameter setting displays in bold to the right of each
button.
FIGURE 3-3 Example rSO2 Dialog (Setup Tab)
4. Select the buttons described in TA
BLE 3-2 to configure the tab.
5. Select the Ca
ncel or Accept button.
•The Cancel button
closes the dialog without saving the settings.
•The Accept bu
tton saves the settings and closes the dialog.
TABLE 3-2
BUTTON DESCRIPTION / COMMENTS CHOICES*
Check INVOS Tone Configures the monitor to sound a distinct
audio
tone when it obtains a Check INVOS
technical message.
On, O
ff
* The factory default configuration settings are in bold.
