Laser Printer Reports Reports
20 - 20 V Series Operating Instructions
20.5.5 Disclosure Detail Report
The Disclosure Detail Report (as shown in FIGURE 20-12 and FIGURE 20-13) shows the detail for the
specific area of disclosure data. A marker (shown as a triangle ) displays above the waveform grid
indicating the date and time the data was recorded. This report includes a header, parameter detail,
and a footer.
NOTE: This report may also be printed from the thermal printer. Refer to
"Configuring the Print Destination" on page 20-5 for additional
information.
FIGURE 20-12 Example Disclosure Detail Report (Page 1) (Laser Printer Output)
To Next Page
