14 - 12 V Series Operating Instructions
14.5.4 Heart Rate (HR) Measurement
If the HR Source is set to Auto, and no other source for HR is available, the NIBP measures the patient’s
heart rate for Neonate, Pediatric, and Adult sizes using a blood pressure cuff. If the system is unable to
measure heart rate, “- -” displays in place of a numeric.
NOTE: Refer to the Heart Rate (HR) chapter for additional information.
14.5.5 Message Area
The message area provides information about the current state of the NIBP parameter. When a
message is displayed, it overwrites the units of measure. If there is more than one message to display,
the messages scroll.
MESSAGE DETAILS
NIBP Systolic High Alarm
Violation
Indicates that the current value is either equal to or higher than the set alarm
limits.
NIBP Systolic Low Alarm
Violation
Indicates that the current value is either equal to or lower than the set alarm
limits.
NIPB Diastolic High Alarm
Violation
Indicates that the current value is either equal to or higher than the set alarm
limits.
NIPB Diastolic Low Alarm
Violation
Indicates that the current value is either equal to or lower than the set alarm
limits.
NIPB Mean High Alarm
Violation
Indicates that the current value is either equal to or higher than the set alarm
limits.
NIPB Mean Low Alarm
Violation
Indicates that the current value is either equal to or lower than the set alarm
limits.
Measuring The NIBP measurement is in process once the cuff begins to inflate.
Deflate The measurement stopped and the cuff deflates.
Retry – Pump Higher The measurement failed due to a reason other than inadequate cuff inflation
pressure or hardware overpressure, and a retry is being attempted.
Cuff Inflation Pressure Failure;
Retry
The measurement failed because of inadequate cuff inflation pressure and a
retry is being attempted.
Unable to Measure The system was unsuccessful in capturing the NIBP measurement. This
message times out with the NIBP data and is based on the NIBP timeout.
Measurement Stopped The measurement ceased before it finished taking the measurement.
Ready to Begin a
Measurement
The monitor is ready to take an NIBP measurement.
Cuff Overpressure The hardware overpressure limit was exceeded.
Check Calibration Software detected that the overpressure transducer is out of calibration.
Press Start NIBP to Clear
Overpressure
The NIBP cuff pressure exceeded the maximum pressure allowed for a given
patient size.
Measurement Failed; Retry The NIBP measurement was unsuccessful and must be retried.
NIBP XXX Out of Range
(where <XXX> is NIBP
Systolic/Diastolic/Mean
pressure)
The NIBP measurement result exceeds the NIBP measurement range.
