Battery Levels Dialog Getting Started
2 - 14 V Series Operating Instructions
2.10.1 Configuring Audio Levels
1. Select the Setup tab from the Navigation Area.
2. Select the Audio Levels button to display the Audio Levels dialog.
3. Adjust the volume levels.
• Select the arrow key to decrease the volume level.
• Select the arrow key to increase the volume level.
NOTE: The icon indicates that the Beep Volume or Technical Volume was
turned off. The Alarm Volume cannot be turned off.
NOTE: The factory default for all three volume levels is medium (shown in
FIGURE 2-13).
FIGURE 2-13 Medium volume level
2.11 Battery Levels Dialog
When batteries are installed and the V 12 is functioning on battery power, the battery indicator
provides a visual reference for the approximate charge level of the batteries. The Battery Levels dialog
(as shown in FIGURE 2-14) indicates which batteries are currently installed; which batteries are
currently being charged; and what the charge level is for each battery.
FIGURE 2-14 Example Battery Levels Dialog
NOTE: The icon indicates that the battery is charging.
