V Series Operating Instructions 17 - 9
CO2 Monitoring (Optional) CO2 Troubleshooting
17.3.6 About the CO
2
Waveform Tile
• The CO
2
waveform tile displays the waveform and the wave gain setting in the configured CO
2
color.
• Provides a scrolling, real-time waveform and an erase bar to provide a time indicator of oldest and
new data.
• The CO
2
waveform tile rails the top most value when the waveform exceeds the upper scale limit
for real-time waveforms.
• The CO
2
waveform tile rails the bottom most value when the waveform exceeds the lower scale
limit for real-time waveforms.
• The CO
2
waveform tile displays the waveform at the configured waveform sweep speed.
17.3.7 Message Area
No messages display in the CO
2
waveform tile message area.
17.4 CO
2
Troubleshooting
The CO
2
tile message area displays messages indicating the current state of the CO
2
parameter. If
there is more than one message to display, the messages scroll.
ISSUE REASON SOLUTION
Do not see CO
2
parameter
tiles in display.
Parameter not configured to display. Refer to "Display Options Dialog" on
page 3-2 for additional information.
“- -” displays in place of
numerics.
Measurement is invalid. Filter may be disconnected. Check
patient.
