11.5.8 IBP Waveform Tile Layout
The IBP waveform tile displays:
1. Tile name
2. IBP waveform
3. IBP waveform scale
4. Unit of measure
5. PA waveform
FIGURE 11-11 Example IBP2 Waveform Tile
FIGURE 11-12 Example ARTPA Overlapping Waveform Tile
NOTE: Refer to "Overlapping Waveform" on page 3-14 for additional
information.
3
4
3
1
2
5
