Hemodynamics Dialog Calculators
22 - 4 V Series Operating Instructions
5. Select the Done button to close the Hemodynamics dialog.
TABLE 22-2 Hemodynamic Calculations
ABBREVIATION /
UNITS DESCRIPTION FORMULA
BSA (m
2
)* Body Surface Area Ht
0.725
(cm) x Wt
0.425
(kg) x 0.007184
CI (l/min/m
2
) Cardiac Index CO / BSA
SV (ml)/beat Stroke Volume (CO / HR) x 1000
SVI (ml/beat/m
2
)Stroke Volume IndexSV / BSA
SVR (dyne-sec/cm
5
)Systemic Vascular
Resistance
(ART mean-CVP) / CO) x 79.96,
Or,
(ART mean-RA) / CO) x 79.96
NOTE: When an IBP channel is labeled RA
and no other IBP channel is labeled
CVP, the RA value is used in
calculating SVR and RVSW.
SVRI (dyne-sec/cm
5
/m
2
)Systemic Vascular
Resistance Index
SVR x BSA
PVR (dyne-sec/cm
5
) Pulmonary Vascular
Resistance
(PA mean-PAWP) / CO) x 79.96
PVRI (dyne-sec/cm
5
/m
2
) Pulmonary Vascular
Resistance Index
PVR x BSA
LCW (kg-m) Left Cardiac Work 0.0136 x ART mean x CO
LCWI (kg-m/m
2
)Left Cardiac
Work Index
LCW / BSA
RCW (kg-m) Right Cardiac Work 0.0136 x PA mean x CO
RCWI (kg-m/m
2
)Right Cardiac Work
Index
RCW / BSA
LVSW (g-m)/beat Left Ventricular Stroke
Work
SV x (ART mean-PAWP) x 0.0136
LVSWI (g-m/beat/m
2
)Left Ventricular Stroke
Work Index
LVSW / BSA
RVSW (g-m)/beat Right Ventricular
Stroke Work
SV x (PA mean - CVP) x 0.0136,
Or,
SV x (PA mean - RA) x 0.0136
NOTE: When an IBP channel is labeled RA
and no other IBP channel is labeled
CVP, the RA value is used in
calculating SVR and RVSW.
RVSWI (g-m/beat/m
2
) Right Ventricular
Stroke Work Index
RVSW / BSA
CoPP (mmHg) Coronary Artery
Perfusion Pressure
Coronary Perfusion Pressure = Diastolic ART Blood
Pressure - PAWP
EDV (ml) End-Diastolic Volume End Diastolic Volume = SV / (EF / 100%)
EDVI (ml/m²) End-Diastolic Volume
Index
End Diastolic Volume Index = EDV / BSA
ESV (ml) End-Systolic Volume End Systolic Volume = EDV - SV
ESVI (ml/m²) End-Systolic Volume -
Index
End Systolic Volume Index = ESV / BSA
*Dubois’ equation
